Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 151
Fig. 78. Isometric Drawing ofCabin. B c.-- ^ Fig. 79. Oblique Projection ofCabin. OFig. 80. Isometric Axes. 111. For the sake of comparison, the samecabin has been shown in Figs. 77, 78, and 79, inthe three different ways. Fig. 77 being a per-spective view; Fig. 78, an isometric drawing;and Fig.…
Architecture · Building
