Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 206
^ … 176 MECHANICAL DRAFTING elevations. Care should be taken to comparethe different views to see that Fig. 137 is theleft side elevation, and Fig. 138 the elevationof the right side. The elevations are to showthe distances between floors, arrangement ofwindows and sizes of glass, and in general…
Architecture · Building
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
