Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 278
smore distinct and is easily changed or erased.After the drawing is completed on this pax5er,then use a cheap, thin paper, and trace through,using a broad, heavy line and colored crayon forcross-sectioning the sections of the work. Yel-low is generally used for wood, red for brick,green for stone,… … BA3t CEILIhC BEAN Fig. 16. A Sheet of Fiill-Sized Details 238 AECHITECTURAL DRAFTmG two for the contractor. One of the copies madeon tracing paper is usually kept in the office,since it can be folded up to a convenient size andfiled, the original and one copy on thin papergoing to the contractor.…
Architecture · Building
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
