ss than one of the equalspaces.) Then, with the same setting of thedividers, begin at C, and lay off the same num-ber of equal spaces as far as X. Measure inthe dividers the distance XB, and lay it off fromX to B. Then the length CB is practicallyequal to AB. The curve, which may or maynot be the… … § P M m 02 O oo H02 W ^ 44 MECHANICAL DRAFTING 45 Again, suppose the circumference of a circleis to be divided into perhaps eleven equal parts.This is most readily and accurately done bytrial, using the hair-spring dividers. Assumefirst some radius, lay this around the circum-ference; and if the…
