pins seen insome of the fine old open-timbered roofs of theMiddle Ages, some architects like all joints inmodern roofs of that class to be pinned withstout wooden pins left standing out a little from 20G PRACTICAL CAEPEXTRY the surface. The writer recently saw a finechurch roof carried out with… … rig. 254. Draw-Eoring for Church Kafter Framing. It was practically impossible to clamp up sucha piece of framing; but, by draw-boring forthe pins, the three oblique shoulders were easilybro^ight tight, and a good job made of it with-out much trouble. riiACTICAL CARPENTEY 297 The method of…
