Fig. 74. riG.75. PRACTICAL CARPExNTRY 59 and a second square will be inscribed within thefirst. The middle points of the sides of this innersquare, as bed, are the centers of the arcs whichstart from the extremities of the diameters. From b, with radius bd, describe an arc, andfrom g, with radius…
