to give the structurestrength; and O.S. the outer or cut string. Ata,a, the ends of the risers are shown; and itwill be noticed that they are mitered against thevertical or riser line of the string, thus prevent-ing the end wood of the riser from being seen.The other end of the riser is in the… … -^ ^ ^ .md _a w.s. 0.5. fcC3 Fig. 77. Plan and Elevation of Open-String Stair. The end of this returned piece is again returnedon itself back to the string, as shown in the FRAJVUNG 143 upper portion of the cut, at n. The moulding,which is a five-eighths cove in this case, is alsoreturned roimd the…
