Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 369
Fig. 182. Trussed Partitions. ties and braces and spiked to them at proper dis-tances apart. If these trussed partitions were calculatedto carry simply their own weight, the dimen-sions of the framing would be as follows: Bot-tom member, 10 inches by 5 inches; inter-tie andtop member, 8 inches by 5…
Architecture · Building
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
