ace as long as possible. CEMENT CONSTRUCTION 101 The State Highway Commission of Illinoisfurnishes advice to township and county high-way officials throughout the State in regard tobridges as well as roads; and in many instances,at the request of local authorities, has suppliedplans and… … Fig. 45. Standard Bridge of 30-Foot Span, Illinois State Highways. In Fig. 44 is shown the standard form ofbridge adopted by the Commission for spans upto 18 feet. This is a slab bridge, and the mainreinforcement is in the direction of the span.The parapets do not carry any of the load. In Fig. 45…
