Fig. 8. Wash Trays or Laundry Tubs. 8, with rough brass continuous waste and trapas in Fig. 9; and are to be supplied with hot andcold water through Fuller bibbs, as shown inFig. 8. The floor drain is like that shown in Fig. 10. Tlie kitchen sink is of the type illustrated inFig. 11, with… … Fig. 10. Floor Drain. Fig. 9. Continuous Waste andTrap from Wash Trays.
