Radford's portfolio of details of building construction : a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale ... (1911)
Radford, William A., 1865-, Johnson, Bernard L, Rawson, Charles P · Chicago : The Radford Architectural Company · leaf 86
APKON. g |j&;-PLASTER. FMG. 1G7 PLATE 73—OUTWARD OPENING CASEMENT—IMPROVED CONSTRUCTION Arrangement for 16 inch brick wall. Fig. 165, cessed space and with joint covered with staff section through window head. Fig. 166, section bead. Fig. 167, section through sill. X indicates through jamb.… … LU<£.- DR1P. PIG.170 PLATE 74—OUTWARD OPENING CASEMENT IN BRICK WALL Improved construction, arrangement for 16 inch to provide air space to keep out dampness. The brick wall. Fig. 168, section through window interior trim is nailed to the grounds (G) and the head. Fig. 169, section through…
