Radford's portfolio of details of building construction : a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale ... (1911)
Radford, William A., 1865-, Johnson, Bernard L, Rawson, Charles P · Chicago : The Radford Architectural Company · leaf 88
g inward this difficulty is muchgreater than with those opening outward. Theconstruction here illustrated will be found per-fectly weather-tight except in exposed locations. Fig. 171, section through window head. Fig. 172,section through jamb. Notice construction of walland application of outside… … PLATE 76—WEATHER-PROOF INWARD OPENING CASEMENT Arrangement in frame walls. The sash andframe are rabbeted at the sill and a small mouldis tongued into the jambs outside of the sash inthe manner shown. This mould is undercut soas to form a channel to catch any water whichmay beat in. This water…
