Radio for everybody; being a popular guide to practical radio-phone reception and transmission and to the dot-and-dash reception and transmission of the radio telegraph, for the layman who wants to apply radio for his pleasure and profit without going into the special theories and the intricacies of the art (1922)

Lescarboura, Austin C. (Austin Celestin), 1891- · New York, Scientific American publishing company [etc.] · leaf 161

An illustration from Radio for everybody; being a popular guide to practical radio-phone reception and transmission and to the dot-and-dash reception and transmission of the radio telegraph, for the layman who wants to apply radio for his pleasure and profit without going into the special theories and the intricacies of the art, 1922, leaf 161
lts. Furthermore, it is necessary to use metallic 142 RADIO FOR EVERYBODY shields between the operator and the components of theregenerative set, since the capacity of the body of theoperator materially affects the delicate adjustments of theregenerative set. Most of the better regenerative… … Another method of obtaining a regenerative receiver. L.—loose-coupler or vario-coupier; VC—variable condenser in pri-mary circuit; VI—variometer in grid circuit; GL—grid leak;A—filament battery; R—filament rheostat; B—*B or platebattery; FC—fixed condenser; T—telephones; V3—plate orfeed-back…
