Richey's guide and assistant for carpenters and mechanics : a work of practical information, giving almost every geometrical and practical problem likely to arise in the work of the carpenter, and quick and easy methods for their solution : the use of the steel square, etc., tables showing strength and weight of materials, methods of framing, useful recipes, etc., etc. (1894)

Richey, H. G. (Harry Grant), b. 1868 · New York : W.T. Comstock · leaf 22

An illustration from Richey's guide and assistant for carpenters and mechanics : a work of practical information, giving almost every geometrical and practical problem likely to arise in the work of the carpenter, and quick and easy methods for their solution : the use of the steel square, etc., tables showing strength and weight of materials, methods of framing, useful recipes, etc., etc., 1894, leaf 22
com-mon rafter until it equals the length of the rafter as i ^zthen draw ^/^ which ij equal to the length of the hip, thencontinue the seats of the cripples until they strike the hip,^^ b, which gives the lengths of the cripples, also the topbevel, which is shown at //; then draw line from £•… … by the lines 2 6, 3 7, 4 8, etc. The bevel at b is the bevelof the foot of the hip; the one at the top is shown aty^. i6 GUIDE AND ASSISTANT

Carpentry
