The American house-carpenter; a treatise on the art of building, and the strength of materials (1867)
Hatfield, R. G. (Robert Griffith), 1815-1879 · New York, J. Wiley · leaf 349
osition for the balusters. Place thecentre of the first baluster, ih. Fig. 291,) I its diameter from theface of the riser, c c?, and i its diameter from the end of the step,e d ; and place the centre of the other baluster, a, half the treadfrom the centre of the first. The centre of the rail must… … 460.— To find the face-mould for a round hand-rail to plat-form stairs. Case 1.— When the cylinder is small. In Fig. 292, j and e represent a vertical section of the last two steps of thefirst flight, and d and i the first two steps of the second flight, ofa platform stairs, the line, e f being the…
Carpentry · Architecture
