Richey's guide and assistant for carpenters and mechanics : a work of practical information, giving almost every geometrical and practical problem likely to arise in the work of the carpenter, and quick and easy methods for their solution : the use of the steel square, etc., tables showing strength and weight of materials, methods of framing, useful recipes, etc., etc. (1894)

Richey, H. G. (Harry Grant), b. 1868 · New York : W.T. Comstock · leaf 97

An illustration from Richey's guide and assistant for carpenters and mechanics : a work of practical information, giving almost every geometrical and practical problem likely to arise in the work of the carpenter, and quick and easy methods for their solution : the use of the steel square, etc., tables showing strength and weight of materials, methods of framing, useful recipes, etc., etc., 1894, leaf 97
-circle and i, 2, 3on d e, as shown; nowdraw lines from the pointsorv a d and d b, at thesame angle and equal inlength to the ones onthe quarter-circle, as i i,2 2, etc.; drive nails inthese points and bendthe strip around.116—When the Span and Rise of an Arc are Given,to Draw the Curve.—Draw the… … Fig. 129 FOR CARPENTERS AND MECHANICS. QI a e and b \ o-^ b f into any number of equal spaces, as i,2, 3, etc.; make 5, 6, 7 equally distant, and draw the linesas shown ; draw the curve through the intersections, asshown.

Carpentry
