The inner part of the material of the pipe ex-posed by cutting, is covered by lines about xVth I … inch apart and inclined 45 degrees. Fig. 253 showsthe same pipe with only a portion of its upper halfcut away; in Fig. 255 is shown this partial sectionof the pipe.
