circular, fig.21, whose thickness is one-ninth of its radius, the line of equalhorizontal thrust just touches the extrados at the crown, andthe intrados at the haunches, pointing out the places wherefailure would take place with a less thickness or an unequalload, by the voussoirs turning on their… … they are well backed up. Pointed arches have a tendency torise at the crown ; and, to prevent this, the cross springersof the ribbed vaults of the middle ages were often made of asemicircular profile, their flatness at the crown being con-cealed by the bosses at their intersections. 70. If the…
