The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics (1872)

Bullock, John · Philadelphia, H.C. Baird & Co. · leaf 425

An illustration from The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics, 1872, leaf 425
e pieces, and the stone may then besafely hoisted, as it is impossible for thelewis to draw out of the hole. By meansof the lewis, in a slightly altered form fromthat here shown, stones can be lowered andset under water without difficulty, the lewisbeing disengaged by means of a line attach-ed to… … ART OF BUILDING. 401

Architecture · Building
