Science and art drawing : complete geometrical course ; consisting of plane and solid geometry, orthographic and isometric projection, projection of shadow's the principles of map projection, graphic arithmetic and graphic statics (1895)
Spanton, J. Humphrey (John Humphrey) · London : Macmillan · leaf 547
is Stt x radius,the radius will be 573°. Draw the line CA = 57-3°. With C as centre, and radiusCA, draw a quadrant till it meets a perpendicular on C in B. 526 SOLID GEOMETRY Divide this quadrant into nine equal parts, and figiire themfrom O to 90. Produce the arc of the quadrant from A to E, and… … Fig. 304. and meeting it in h. From the centre C draw the arc AG-. Thisis the plan of the arc of 70° latitude. At A draw a perpendicular to CA, and make Ac equal tothe arc AE (Prob. 192, Plane Geometry). Draw ef parallel toAC. These two lines will represent the distance of 20° apartof the meridians…
Geometrical drawing
Internet Archive · Wellesley College Library · Public Domain Mark 1.0. Free to use for anything.
