r hammer and permits inspection when needed. The in-sulated anvils are connected in muliple to the single wire, markedB on the accompanying cut. In other particulars, the electric ar-rangements are not different from the mechanical generatorsystem long used on the Mors carriages. The motor is… … Fig. 252.—Side Elevation of the Cadillac Motor, showing- connections foroperating- the valves and speed gear on the main shaft. The Cadillac One=CyIinder Motor.—The single-cylindermotor of the Cadillac carriage embodies a number of featuresof exceptional interest. Its high power efficiency may be…
