Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)

Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 372

An illustration from Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles, 1906, leaf 372 — two sections of two spurs each.Each section is shifted by an arm projecting downward from a TYPICAL GASOLINE CARRIAGES. 359 horizontal rod bearing a rack on the outer end. Further-more, these two rack rods are set side by side, so that a toothedsector on the lower extremity of the hand lever may… … 2ZZZZZZZZZZZZZZZZZZZZZZZZZZ2ZZZ Fig. 270.—Transmission Gear of the Cannstadt-Daimler Carriage shown inthe last figure. Here, A is the hand lever; B, the gridiron quadrant; C,a dog on the lever for throwing out the clutch in shifting the gears;E, toothed sector at end of A for actuating rack rods D…

Automobiles

Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
