Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 373
Fig. 271.—Details of Side-shifting Change Lever of the Cannstadt-DaimlerCar. A is the lever, pivoted between bearings, B and C. D is the toothedsector, which may be shifted to engage either of the rack rods, E or F;Lis a downward extension from the pivot rod of A, carrying the sector,G, which may…
Automobiles
Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
