Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 41
Fig. 25.— Section through the axis of a bevel gear differential train, showing two bevelpinions attached at top and bottom of the sprocket drum, and two bevel gearwheelsone on the through axle shaft, the other on a rotating sleeve. pinions against the collars, with consequently excessive wear…
Automobiles
Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
