Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 415
Fig. 309.—Mechanism of the Expanding Band Clutch of the Columbia LightCar. … Fig. 310.—Transmission and Clutch of the Columbia Light Car. A, spurgear on the clutch shaft; B and C, spurs on the squared second shaft,the first shifted by fork hung at H, by lever, H (last figure), the secondby fork at J by lever, J. D, E, F, G, three-speed pinions keyed tocountershaft; K,…
Automobiles
