Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)

Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 436

An illustration from Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles, 1906, leaf 436 — ; Bouton carriages consists of a hollowdriving shaft, A, on which are two loose gears and their clutchdrums, C and D, and a secondary shaft, to which are keyed twospur pinions, G and H. Within the hollow driving shaft, A, TYPICAL GASOLINE CARRIAGES. 423 slides a round shaft, S, upon the extremity… … do +-> opq O & c302 O CD o AC; So o fc the pinions, 0, P, Q and R, which are mounted on right and leftthreaded axles, screwing into adjustable bearings or sleeves.Consequently, as may be understood, the longitudinal movementof the screw rack, turning the pinions on their screw axles, tends…
