Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 454
ovingthence entirely around both pole cores, thence to the outside lineand back through the other brush. (2) Shunt-wound dynamos are wound in the same fashion asthe series-wound, with the exception that the pole cores arewound with a large number of turns of high resistance wire, thefield windings,… … Fig. 335.—A Typical Dynamo-Electrical Generator, with parts lettered. A, the arma-ture; B, B, the brushes; C, the commutator; E, E, the windings of the field magnets;M, the pole piece of the salient field magnet; F, F, bearings of the armature spindle;L, L, the lead wires; P, the pulley; T, T,…
Automobiles
