Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 69
s of universal joints. The frontwheels rotate in pivoted bearings, so as to be effectually turned 56 SELF-PROPELLED VEHICLES. in steering, without interfering with their motion on their ownaxes, or in any way altering the action of the motor. As may bereadily understood, a proper arrangement of… … Fig. 56.—Recently Patented Device for Driving on all Four Wheels by a System of Uni-versal joints. The steering arms are not inclined, since the wheels being driven fol-low their paths without slipping. All-Wheel Driving and Steering.— The advantages to begained in a practical device for applying…
Automobiles
