Shop practice for home mechanics, use of tools, shop processes, construction of small machines. Contains a chapter also on theoretical mechanics and on miscellaneous information relative to shop work (1920)
Yates, Raymond F. (Raymond Francis), 1895- · New York, N. W. Henley Pub. Co. · leaf 177
t is the same, the worK: into the toolwhich is the case with the boring bar. The work ofmounting pieces for boring will be treated more in detailin a later chapter. A boring bar with an adjustable tool is shown in thecross-section, Fig. 210. The cutting tool used is groundto shape from a rod of… … Fig. 2IO—An adjustable cutter mounted in a boring bar cuts are taken. It must be remembered that when workis mounted upon the carriage of the lathe the cross-feedcannot be used to adjust the cut. This Avould result inboring an eccentric hole, therefore it is necessary to ad-just the cutting tool on…
Machine-shop practice · Handicraft
