Shop practice for home mechanics, use of tools, shop processes, construction of small machines. Contains a chapter also on theoretical mechanics and on miscellaneous information relative to shop work (1920)
Yates, Raymond F. (Raymond Francis), 1895- · New York, N. W. Henley Pub. Co. · leaf 183
Fig. 217—How a double throw crankshaft is cut from the rough for turning from the start to the fmish. It is, of course, necessar^^to shift from the centers on one side to the centers onthe other to turn the two crank pins. The positions ofthe centers for the turning of the crankshaft is sho^^^l…
Machine-shop practice · Handicraft
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
