A short treatise on the designing and construction of gearing and mill-work. Accompanied by an explanation of the construction and use of the odontograph of Prof. Willis .. (1873)

[Scott, David] engineer. [from old catalog] · New York, D. Appleton and company · leaf 91

An illustration from A short treatise on the designing and construction of gearing and mill-work. Accompanied by an explanation of the construction and use of the odontograph of Prof. Willis .., 1873, leaf 91
ests against the guide,and so connected, either with the guide-bar or some other part of the machinery, that at the time of thecutting motion it will move forward, that its bevelled surface may be brought in contact with the guideand give a lateral motion to the guide-bar, to relieve the cutter… … In the accompanying figures, a represents the main frame of the machine, to the inside of which isadapted a frame h that carries the spindle c of an index-plate, made in the usual manner. This frameh is secured to the main frame by the bolts ddthat pass through elongated holes eem the side piecesof…

Gearing · Mills and mill-work · Odontograph
