Small motors, transformers, electromagnets; a practical presentation of design and construction data for small motors, small low- and high-tension transformers, electromagnets, and induction coils (1920)
Stoller, Hugh Montgomery, Austin, F. E. (Frank Eugene), 1873-, Seeger, Edwin Wilbur, 1892- joint author, American Technical Society · Chicago, American Technical Society · leaf 308
Fig. 31. Operation of Separator Pulley bammers, etc., before the coal is taken into the crushers; and forprotecting crushers and other machinery in various industries. Lifting Magnet. One of the best-known applications of theelectromagnet is the lifting magnet. Fig. 32 shows a cross- … [c) (£; CB) ce: Fig. 32. Lifting Magnet Details section of such a magnet built by the Cutler-Hammer Manufac-turing Company. The magnet consists essentially of a heavycast-steel framework A in which is placed a strap-wound impreg- 295 56 ELECTROMAGNETS AND COILS nated coil B. C and D are the inner…
Electric motors · Electric transformers · Electromagnets · Induction coils
