Small motors, transformers, electromagnets; a practical presentation of design and construction data for small motors, small low- and high-tension transformers, electromagnets, and induction coils (1920)

Stoller, Hugh Montgomery, Austin, F. E. (Frank Eugene), 1873-, Seeger, Edwin Wilbur, 1892- joint author, American Technical Society · Chicago, American Technical Society · leaf 87

An illustration from Small motors, transformers, electromagnets; a practical presentation of design and construction data for small motors, small low- and high-tension transformers, electromagnets, and induction coils, 1920, leaf 87 — TYPE 5A. FORM SI. FRAME 165.MAIN WINDING … Fig 30. Main Winding for Western Electric Type SA, Form SI, Frame 165, Single-Phase Induction Motor Consider the instant when the center of one of the fourregions of maximum flux density comes under tooth 7, which isthe center of one of the four groups of turns. The flux throughthe teeth in the…

Electric motors · Electric transformers · Electromagnets · Induction coils

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
