Ludy, Llewellyn V., 1875- [from old catalog], American Technical Society · Chicago, American technical society · leaf 124
edge of the valve overlaps the right-hand edgeof the port by an amount equal to EiE2 when the valve has reachedits maximum displacement. Fig. 23, with its two valve circles, shows the diagram for thehead end of the cylinder only. The crank-end diagram would besimilar except that the laps might not… … xf\RELEASE^^ HEAD END \ADA//SS/ONCRANK END HEADEND RELEASE ,CRANK END \$ COMPBE3SJONHEAD END CRANK END CUT-OFFCFiANK END Fig. 24. Diagram Analysis for Movement of a Direct Valve as RegardsHead End of Cylinder advance, maximum and minimum port opening, steam lap, andexhaust lap. Generally, if four…
Indicators for steam-engines · Steam-engines
