Creighton, William Henry Paul, 1859- · New York, J. Wiley & sons; [etc., etc.] · leaf 339
vely. t In the single cards the high- and low-pressure diagrams are ofapproximately the same length. Since there is a radical differencein the volumes represented by the lengths of the cards, there mustbe a radical difference in their scale of volumes. Similarly thescale of pressure in each card is… … --C.04CLEARANCE -i 130 120 no 100 90 30 70 60 50 40 30 20 10 1014.7 >f«~>t 0.178^4«-*{ 4.3^-0.48 MULTIPLE-EXPANSION ENGINES. 319 To Draw the Combined Diagram.—Draw any line to representthe clearance line as in Fig. 163. Perpendicular to it, at any givenpoint, erect a line, called the zero…
Steam-engines · Heat-engines
