Thermodynamics of the steam-engine and other heat-engines (1907)
Peabody, Cecil H. (Cecil Hobart), 1855-1934 · New York, J. Wiley & sons; [etc., etc.] · leaf 182
TRIPLE ENGINES 173 intermediate, as shown by Fig. 45, the diagrams are Hke thosegiven by Fig. 46. The admission and expansion for the high-pressure cyKnder are represented by ahc. When the high-pressure piston is at release, its crank is at H, Fig. 45, and theintermediate crank is at /, so that the…
Thermodynamics · Steam-engines · Heat-engines
