Creighton, William Henry Paul, 1859- · New York, J. Wiley & sons; [etc., etc.] · leaf 487
ecause ofthe scale required for clearness. 5. That the velocity of the steam increases in the stationarycircle of vanes. In the revolving vanes it first decreases andthen increases. 6. That the fall of pressure is practically uniform and occursin both the stationary and revolving circles of vanes.… … M-4) Fig. 244. SUPERHEATED STEAM AND STEAM-TURBINES. 467 DIAGRAM AS MODIFIED BY FRICTION LOSSESFIRST STAGE
Steam-engines · Heat-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
