Pomilio, Ottorino · New York, McGraw-Hill · leaf 299
Scale of Moments Fig. 169. … Fig. 170. Then the difTerence between the ordinates of the parabolasand those of the diagram AA B C D D give us the diagramXAa B y C c D YX which represents the diagram ofthe bending moment (Fig. 169). Knowing the diagram of the bending moments, it is easy MAIN PLANES AND CONTROL SURFACES 285…
Airplanes
