Creighton, William Henry Paul, 1859- · New York, J. Wiley & sons; [etc., etc.] · leaf 489
t#=9S5: TWO STAGE IMPULSE TURBINE,Fig. 245. 468 THE STEAM-ENGINE AND OTHER HEAT-MOTORS. DIAGRAM AS .MODIFIED BY FRICTION LOSSES;SECOND STAGE. … The entrance and exit angles of the buckets,•whether moving or stationary, are not neces-sarily made equal to each other, but aremodified to suit the energy distribution aimedat in any given case. Fig. 246. SUPERHEATED STEAM AND STEAM-TURBINES. 469
Steam-engines · Heat-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
