Creighton, William Henry Paul, 1859- · New York, J. Wiley & sons; [etc., etc.] · leaf 512
s in GAS-ENGINES AND GAS-PRODUCERS. 491 a few particulars. The practical card. Fig. 18%, differs verymaterially from the theoretical one, taking some such form asABCDFBA, or, when the engine is not properly adjusted, somesuch form as that indicated by ABCDEBA. The entropy analysis given below is… … Fig. 258. of B is sufficient to indicate the thermal characteristics of the fujlgas charge. If the compression is truly adiabalic, BC is thecourse of our tracing-point. If the walls absorb heat there will bea loss of entropy, and the tracing-point will wander to the left.The charge is fired and the…
Steam-engines · Heat-engines
