Steam engines, a thorough and practical presentation of modern steam engine practice (1920)
Ludy, Llewellyn V., 1875-, American Technical Society · Chicago, American technical society · leaf 97
Kg. 61. Portion of Marine Engine Crank Showing Method of Bolting Sections Together center of the shaft is the least effective of any part of it in resistingtwisting forces, and the outside is the most effective. By using a. little larger shaft, therefore, and removing considerable metal fromaround… … Fig. 62. Typical Marine Thrust Bearing usually all made of the same size, so as to be interchangeable, and thusrequire fewer parts to be kept in stock. Bearings. The bearing. Fig. 62, while not part of the engme,will nevertheless be discussed at this point. This is called the thrustbearing, and is…
Steam-engines
