illustratethe principles involved in governor design, including the values ofF for varying positions of the balls, and for varying weights on thesleeve, from which the corresponding speed may be calculated. In a Porter governor as illustrated by Fig. 222, it will be seen that GOVERNORS. 205 the… … Fig. 221. If a load had been put on the balls as in Fig. 223, then the verticalmovement of the balls and the sleeve would be equal, but in Fig. 222the vertical movement of the central load is twice that of the ball.
