nthe cylinder clearances are cut down to -g- in. or -j=^ in., the lengthof connecting-rod must remain approximately constant. Whenconnecting-rods (Figs. 316, 317, and 318) are used, the crank-pinis fitted with a loose cap, having a nipple going into the recessin crank, and held in place by studs… … Fig. 317. 270 STEAM-ENGINE THEORY AND PRACTICE,
