The steam engine and turbine; a text-book for engineering colleges (1911)
Heck, Robert Culbertson Hays, 1870- · New York, D. Van Nostrand company · leaf 367
if I Fig. 208. — Crosshead from Engine in Fig. 2, of four-bar type.. View D showsgrooves in bottom face which are filled with babbitt metal, so that rubbingsurface is partly babbitt, partly cast iron: view E shows how wrist pin is lubri-cated by oil caught from guides. Scale 1 to 10.
Steam-engines · Steam-turbines
