Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 198
Fig. 201.—View Of Crank-End Of A Motor-Driven Boiler-Feed Pump. Gate Valve— driving Motor \ Shaft Coupling -<—Feed-P/pe To BoilersMulti-Stage Centri-fugal Pump- … Suction Pipe From Feed-Water Heater-- Fig. 202.—Centrifugal Boiler-Feed Pump Motor-Driven Through Direct Shaft Connection.12 178 STEAM POWER PLANT AUXILIARIES [Div. 6 pump operated directly by steam from the boiler and inde-pendently of the engine. In small plants they will be recipro-cating pumps…
Steam power plants · Pumping machinery
