ler. When the bowl B2 tilts under the weight of the accumulatedwater, steam at boiler pressure enters through the pipe P2. The pres-sure in the trap and in the boiler is thus equalized. Due to its statichead of 3 ft. or more, the water in the bowl B2 flows, by gravity, into theboiler through the… … Wafer Connections On Reverse End— \ \J^:--Live Steam InletExhaust Stzam Outlzi Fig. 217.—Farnsworth Duplex Boiler Feeder. This feeder is recommended by its manufacturers for boiler-feeding in non-condensing plants where water from the mains Cho<mbzr-%; -Chamber-fr 3H C3C^..,.....CTl^.11 >:■.■•
