aft F can be driven ineither direction by means of the bevel gears and clutch on shaft B, theclutch being moved by a lever. 629. Plan of intermediate gears and spring pin. 630. VARIABLE DRIVE MOTION. Two cone pulleys mountedwith differential spur gear on the driving shaft with a cross arm and bevel… … SECTION XV. MOTION AND CONTROLLINGDEVICES. ETC 243 Section XV. MOTION AND CONTROLLING DEVICES, ETC.
