Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 247
eed-water enters the heater (Fig. 235) throughthe pipe F. The rate of flow is controlled by the valve V, which is oper-15 226 STEAM POWER PLANT AUXILIARIES [Div. 7 ated by the float H. The water rains down through the perforatedplate R and passes successively through the filter beds Mi and M.… … \ P.umpSupply WmH, FQunotoifiQn Fig. 238.—Cochrane Open Induction Feed-Water Heater. The exhaust steam enters the heater (Fig. 235) through the nozzle E,and (Fig. 236) is diverted to a downward flow, through the cups C, intothe separating chambers S. The momentum of the oil-particles precipi-tates…
Steam power plants · Pumping machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
