Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 279
5 and 262) of a gearedmechanism. The soot, which is scraped off by the beveled edges of thesleeves, falls into a pit beneath the economizer. It is then removed 17 258 STEAM POWER PLANT AUXILIARIES [Div. 8 through clean-out doors. Or, the soot may drop into a pit (Fig. 255)whence it is conveyed away… … Fig. 262.—Mechanism For Automatic ReversalOf Travel Of Soot-Scrapers On Green Fuel-Economizers. Bevel-Gear Pinions B\ And BiAre Loose On Shaft S.
Steam power plants · Pumping machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
