Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 286
r and the combustion-gases enter the economizer at the same end. Thus the coolestpart of the water-current abstracts heat from the hottest partof the gas-current. For a contra-flow (Fig. 271) the feed-water and the gases enter the economizer at opposite ends.Thus the water is first heated by the… … y-Feed-Water Inlet Fig. 270. — Illustration Of WaterAnd Gas Flow In Parallel Flow Econ-omizer Installation. -Feed-Wafer Outlet r^\ r^ r^\ <c\ ^ ^Wtosto
Steam power plants · Pumping machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
